Gotham Lighting (Acuity Brands Lighting)
EVO2WW. EVO General Illumination Round Wallwash Downlight 2”.
Configure
Add to project
RESOURCES
DESCRIPTION
OPTICS
EVO® batwing distribution provides a uniform, wide angled general illumination on horizontal and vertical surface to create smooth edges and an even layer of light without hot spots or rings.
PERFORMANCE
Our high-performing downlights provide the quality of light needed to create multiple layers of light within a space.
DESIGN
For wherever you specify downlights, we offer an ample array of installation options, trims, sizes, and colors allowing for a complete custom design.
EVO® batwing distribution provides a uniform, wide angled general illumination on horizontal and vertical surface to create smooth edges and an even layer of light without hot spots or rings.
- Cutoff: 45°
- Functions: Open, corner, and double wall wash, and lensed wall wash solutions
- Trim options: Self-flanged, flangeless
PERFORMANCE
Our high-performing downlights provide the quality of light needed to create multiple layers of light within a space.
- Bounding Ray™ technology eliminates flash for superior glare control
- Lumens: 250-1,500 LM
- Listings: Energy Star, UL, Damp Location, Wet Location
- Driver capabilities: Up to 10 different driver options from 0-10v to DMX
- Controls: nLight® wired and wireless lighting controls
DESIGN
For wherever you specify downlights, we offer an ample array of installation options, trims, sizes, and colors allowing for a complete custom design.
- Reflector finishes: Semi-specular, matte diffused
- Optics: Easy field-interchangeable optics
- Trims: Minimal 3/8” trim flange
- Ceiling types: Metal, wood, drywall, and suspended grid ceilings
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 2 1/4"L: 2 1/4"
- Light SourceLED
- CCT/Color2700K3000K3500K4000K5000K
- CRI90 85
- Watt(Approx)3.4 W6.3 W9.7 W12.7 W21.2 W
- Lumens(Approx)207 Lm421 Lm626 Lm837 Lm1199 Lm
- OpticsDirectAsymmetric/Wash
- Adjustable
- DimmingDim to 1%TRIAC/Forward/LeadingELV/Reverse/Trailing0-10V
- Controls/NetworknLight®
- Power/VoltageIntegralUNV 120-277V120V277V
- Integral Emergency
- Lumen Maintenance60000 h
- CertificatesCSAMade in USABAA
- EnvironmentDamp
- Mounting TypeCeiling RecessedDrywallTrimless DrywallT-Grid Ceiling
- HousingNew ConstructionChicago PlenumIC Air Tight
- Housing Depth6 1/8 ''7 3/16 ''
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
Lead timeEVO2WW
Cost
—
CONFIGURATORDESCRIPTIONDIMENSIONSLIGHT SOURCEWATT/LUMENSPOWER/CONTROLSYou reconfigured the product. To remove this message please update you custom description.Marks unavailable product configuration, refer to manufacturer’s documentation for details
BUILD CATALOG NUMBER
