Lithonia Lighting (Acuity Brands Lighting)
BEY. Beyond LED High Bay.
 Configure
 Add to project
Lithonia Lighting. BEY. Beyond LED High Bay.
Lithonia Lighting. BEY. Beyond LED High Bay.
Lithonia Lighting. BEY. Beyond LED High Bay.
Lithonia Lighting. BEY. Beyond LED High Bay.
RESOURCES
DESCRIPTION
Introducing the Beyond by Lithonia Lighting® - a linear high bay purposefully built to serve you. Beyond offers effortless selection through expertly curated trim packages pre-configured for the most common high bay applications, in addition to a breadth of configurable options tailored to fit the needs of any space. Backed by a sleek patent-pending thermal design for maximum performance and efficiency, all while pushing past the standard with our highest lumen output yet.

Built for Better:

  • Selection: Simplify ordering and save time with trim packages built for the most common high bay applications.
  • Spaces: Beyond can fit seamlessly into any space with 3 sizes, 4 CCTs, 5 distributions, 6 mounting options and lumens up to 100,000+
  • Sustainability: All configurations are powered by a patent-pending thermal design, delivering a single high-efficiency platform with performance up to 200+ LPW.
MORE DESCRIPTION
SPECIFICATIONS
  • Dimensions
    W: 8.54"14.7"20.87"
    L: 24"48"
    H: 5.19"
  • Light Source
    LED
  • CCT/Color
    3000K3500K4000K5000K
  • CRI
    80 90
  • Watt(Approx)
    44 W68 W82.5 W95.5 W129.1 W166.3 W204.3 W246 W334.3 W408.6 W426.7 W484.4 W542.5 W
  • Lumens(Approx)
    8013 Lm12315 Lm15712 Lm18212 Lm24669 Lm31071 Lm36930 Lm50273 Lm62774 Lm73097 Lm82470 Lm92720 Lm102845 Lm
  • Optics
    DirectNarrowMediumWide FloodGeneral Diffused
  • Adjustable
  • Dimming
    Dim to 3-10%0-10V
  • Controls/Network
    nLight®Integral Sensor
  • Power/Voltage
    IntegralUNV 120-277V120V208V220-240V277VUNC 347-480V347V480V
  • Integral Emergency
    EM Integral
  • Lumen Maintenance
    100000 h
  • Certificates
    CSADLC*
  • Environment
    DampIP65
  • Mounting Type
    PendantCeiling Surface
  • Housing
  • Housing Depth
