Axis Lighting
DIALED. Dia 2x2 LED RECESSED T-Bar & Drywall.
Configure
Add to project
RESOURCES
-
SPEC SHEET
-
WHERE TO BUY
-
MANUFACTURER'S PAGE
-
ASK MANUFACTURER
DESCRIPTION
Visual comfort, energy efficiency and no pixilation on the lens make the slender design of Dia LED more appealing than ever. Dia LED creates a clean ceiling line and a distinctive, architectural esthetic that integrates well into contemporary spaces.
Most Dia LED models meet the low power density requirements of sustainable lighting projects, including IESNA RP-1-04 guidelines. Optional integral controls options provide additional energy savings.
Luminaires come with air return option and time-saving features, such as a hinged center optic component and driver covers. The low-profile design (only 3.875” deep) is well-suited to shallow plenums.
Most Dia LED models meet the low power density requirements of sustainable lighting projects, including IESNA RP-1-04 guidelines. Optional integral controls options provide additional energy savings.
Luminaires come with air return option and time-saving features, such as a hinged center optic component and driver covers. The low-profile design (only 3.875” deep) is well-suited to shallow plenums.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 2 FtL: 2 Ft
- Light SourceLED
- CCT/Color2700K3000K3500K4000KTunable White
- CRI80 90
- Watt(Approx)23.1 W28.49 W39.22 Wcustom
- Lumens(Approx)1600 Lm2500 Lm3000 Lm4000 Lm4500 Lmcustom
- OpticsDirectGeneral Diffused
- Adjustable
- DimmingDim to 3-10%Dim to 1%Bi-Level0-10VDALILutron Hi-lume EcoSystem (LDE1)Xitanium SRDMX
- Controls/NetworkEthernetEnlightedWireless DimmingIntegral Sensor
- Power/VoltageIntegralPoEUNV 120-277V120V277V347V
- Integral EmergencyEM Integral
- Lumen Maintenance50000 h
- CertificatesUL/CULNYC
- EnvironmentDamp
- Mounting TypeCeiling RecessedDrywallT-Grid CeilingSlot T-Grid Ceiling
- HousingICChicago PlenumAir Return
- Housing Depth3 7/8 ''
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
Lead timeDIA22RLED
Cost
—
CONFIGURATORDESCRIPTIONDIMENSIONSLIGHT SOURCEWATT/LUMENSPOWER/CONTROLSYou reconfigured the product. To remove this message please update you custom description.Marks unavailable product configuration, refer to manufacturer’s documentation for details
BUILD CATALOG NUMBER
