SK2R. Sketch 2 RECESSED.
Configure
Add to project
RESOURCES
-
SPEC SHEET
-
WHERE TO BUY
-
MANUFACTURER'S PAGE
-
ASK MANUFACTURER
DESCRIPTION
Light Distribution
Direct
Output
Up to 1100 lm/ft
Efficacy
Up to 115 lm/W
Segments
2 ft minimum
Any curve radius over 12"
Direct
Output
Up to 1100 lm/ft
Efficacy
Up to 115 lm/W
Segments
2 ft minimum
Any curve radius over 12"
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 2 9/32"L: Run length (inch)
- Light SourceLED
- CCT/Color2700K3000K3500K4000K
- CRI80 90
- Watt(Approx)9.85 W/Ftcustom
- Lumens(Approx)300 Lm/Ft1100 Lm/Ftcustom
- OpticsDirectGeneral Diffused
- Adjustable
- DimmingDim to 3-10%Dim to 1%0-10VDALILutron Hi-lume EcoSystem (LDE1)Xitanium SRDMX
- Controls/Network
- Power/VoltageIntegralRemotePoEUNV 120-277V120V277V347V
- Integral Emergency
- Lumen Maintenance50000 h
- CertificatesUL/CUL
- EnvironmentDamp
- Mounting TypeCeiling RecessedDrywall
- HousingNew Construction
- Housing Depth3 1/2 ''
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
Lead timeSK2R
