Bega US
84 294. In-grade luminaire Symmetric.
Configure
Add to project
RESOURCES
DESCRIPTION
A round in-grade intended for the illumination of walls, foliage, and architectural features. Designed to bear pressure loads up to 11,000 lbs. from vehicles with pneumatic tires. The luminaire must not be used for traffic lanes where it is subject to horizontal pressure from vehicles braking, accelerating, or changing direction.
Die-cast aluminum housing · Stainless steel faceplate · Clear or white safety glass · floodlight reflector made of pure anodized aluminum
LED color temperatures: 2700K, 3000K, 3500K, 4000K
Brushed stainless steel. Custom colors are not available.
BEGA Tricoat ®, A 3-layer finishing technology for increased corrosion protection.
NRTL listed to North American standards - Suitable for wet locations - Protection class IP 67
Die-cast aluminum housing · Stainless steel faceplate · Clear or white safety glass · floodlight reflector made of pure anodized aluminum
LED color temperatures: 2700K, 3000K, 3500K, 4000K
Brushed stainless steel. Custom colors are not available.
BEGA Tricoat ®, A 3-layer finishing technology for increased corrosion protection.
NRTL listed to North American standards - Suitable for wet locations - Protection class IP 67
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 8 1/8"L: 8 1/8"
- Light SourceLED
- CCT/Color2700K3000K3500K4000K
- CRI80
- Watt(Approx)16 W
- Lumens(Approx)1691 Lm
- OpticsDirectWide Flood
- Adjustable
- DimmingDim to 3-10%TRIAC/Forward/LeadingELV/Reverse/Trailing0-10V
- Controls/Network
- Power/VoltageIntegralUNV 120-277V
- Integral Emergency
- Lumen Maintenance60000 h
- Certificates
- EnvironmentMarineIP68
- Mounting TypeIn-GradeConcrete Drive Over
- Housing
- Housing Depth
