BYIBA Light (Gordon Bullard)
BY-4247Z-9010. MINILED DIAGO (ceiling recessed).
Configure
Add to project



RESOURCES
DESCRIPTION
The MINILED DIAGO recessed light is an Italian-designed architectural fixture that delivers precise, expressive illumination with a refined minimalist appearance.
Its diagonal light emission creates a distinctive visual effect while allowing flexible control of light direction and atmosphere.
Designed for both ceilings and walls, it integrates seamlessly into modern interiors and accent lighting schemes.
Made from high-quality materials with excellent durability and finish, it combines advanced LED technology with elegant design.
Its diagonal light emission creates a distinctive visual effect while allowing flexible control of light direction and atmosphere.
Designed for both ceilings and walls, it integrates seamlessly into modern interiors and accent lighting schemes.
Made from high-quality materials with excellent durability and finish, it combines advanced LED technology with elegant design.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 4.3"L: 4.3"
- Light SourceLED
- CCT/Color2700K3000K4000K
- CRI90
- Watt(Approx)4 W6 W8.5 W11 W
- Lumens(Approx)450 Lm480 Lm510 Lm630 Lm660 Lm690 Lm820 Lm850 Lm880 Lm1020 Lm1050 Lm1080 Lm
- OpticsDirectMediumFloodWide FloodAsymmetric/Wash
- Adjustable
- DimmingDim to 3-10%Non-Dim0-10VDALI
- Controls/NetworkLutron®Casambi
- Power/VoltageRemoteUNV 120-277V
- Integral Emergency
- Lumen Maintenance
- CertificatesETL
- Environment
- Mounting TypeCeiling RecessedDrywall
- HousingFixture
- Housing Depth1.18 ''
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
Lead timeBY-4247Z-9010
—
