Pivot 1.7 Adjustable LED Floodlight, Ø1.6'', 3.5W / 5W / 7W, 463 lm, IP66.
Configure
Add to project
RESOURCES
-
SPEC SHEET
-
WHERE TO BUY
-
MANUFACTURER'S PAGE
-
ASK MANUFACTURER
DESCRIPTION
Pivot 1.7 is a compact outdoor projector available in a wide range of optics that can be surface mounted, used with a fastener strap, or ground spike. Adjustable 360° on the horizontal axis and 60° up, 20° down on the vertical axis.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 1.57"L: 2.59"H: 1.57"
- Light SourceLED
- CCT/Color2700K3000K4000K
- CRI80 90
- Watt(Approx)3.5 W5 W7 W
- Lumens(Approx)177 Lm352 Lm463 Lm
- OpticsDirectGrazingNarrowMediumFloodWide FloodAsymmetric/Wash
- AdjustableAdjustable
- DimmingDim to 3-10%Dim to <1%Non-Dim0-10VLutron Hi-lume Premier Eco (L3D0E)
- Controls/Network
- Power/VoltageRemoteUNV 120-277V120V
- Integral Emergency
- Lumen Maintenance50000 h
- CertificatesETL
- EnvironmentIP66
- Mounting TypeGround Spike/StakeSurfaceKnuckleTree Strap
- Housing
- Housing Depth
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
Lead timeCP170
Cost
—
CONFIGURATORDESCRIPTIONDIMENSIONSLIGHT SOURCEWATT/LUMENSPOWER/CONTROLSYou reconfigured the product. To remove this message please update you custom description.Marks unavailable product configuration, refer to manufacturer’s documentation for details
BUILD CATALOG NUMBER
