Neva 2.0-2.2 Recessed Linear Profile LED, Various Wattages, IP67. by Designplan

Designplan

Neva 2.0-2.2 Recessed Linear Profile LED, Various Wattages, IP67.

Configure

Add to project

RESOURCES

DESCRIPTION

The Neva 2 series is a linear profile with deep-set optics perfect for architectural lighting and outdoor applications. It is available in 4 different lengths. Recessed mounting available with outer casing or surface mounting using adjustable brackets.

MORE DESCRIPTION

SPECIFICATIONS

Dimensions
W: 1.46"
L: 12.44"26.65"40.83"69.21"
Light Source
LED
CCT/Color
2700K3000K4000K
CRI
80
Watt^(Approx)
5.5 W7.5 W11 W15 W16 W22 W27 W38 W
Lumens^(Approx)
345 Lm483 Lm690 Lm966 Lm1035 Lm1450 Lm1725 Lm2415 Lm
Optics
DirectGrazingNarrowFlood
Adjustable

Dimming
Dim to 3-10%Dim to <1%Non-DimTRIAC/Forward/LeadingELV/Reverse/Trailing0-10VLutron Hi-Lume 3-wire (L3D)
Controls/Network
Power/Voltage
RemoteUNV 120-277V120V
Integral Emergency
Lumen Maintenance
50000 h
Certificates
ETL
Environment
IP67
Mounting Type
In-GradeConcrete Drive Over
Housing
Housing Depth

SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.

NV-REC-20-22

Lead time Cost —

CONFIGURATOR

Description:

DESCRIPTION

DIMENSIONS

LIGHT SOURCE

WATT/LUMENS

POWER/CONTROLS

i You reconfigured the product. To remove this message please update you custom description.

Marks unavailable product configuration, refer to manufacturer’s documentation for details

BUILD CATALOG NUMBER

PRODUCT DESCRIPTION
—

The Neva 2 series is a linear profile with deep-set optics perfect for architectural lighting and outdoor applications. It is available in 4 different lengths. Recessed mounting available with outer casing or surface mounting using adjustable brackets.
