Edison Price
EPD-6ADJ. 6” Adjustable Architectural LED Downlight.
Configure
Add to project
RESOURCES
DESCRIPTION
– Exceptional Optical Quality: Up to 98 CRI, 1×2 Step MacAdam Ellipse.
– Shipped standard with a Solite Beam Smoother lens that removes striations from the light source.
– Availble with a multitude of dimming protocols and control offerings.
– Shipped standard with a Solite Beam Smoother lens that removes striations from the light source.
– Availble with a multitude of dimming protocols and control offerings.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 7"L: 7"
- Light SourceLED
- CCT/Color2400K or less2700K2700K Dim to Warm3000K3000K Dim to Warm3500K4000K5000K
- CRI90 98
- Watt(Approx)12 W16 W20 W22 W36 W46 W72 W
- Lumens(Approx)1065 Lm1398 Lm1785 Lm2252 Lm3374 Lm4649 Lm6696 Lm
- OpticsDirectNarrowMediumFloodWide Flood
- AdjustableAdjustable
- DimmingDim to 3-10%Dim to 1%Dim to <1%TRIAC/Forward/Leading0-10VLutron Hi-lume EcoSystem (LDE1)Xitanium SRLutron Hi-lume Premier Eco (PEQ0)eldoLED SOLO DALIeldoLED SOLO 0-10VeldoLED SOLO DMX
- Controls/NetworkEthernetBluetoothCasambi
- Power/VoltageIntegralUNV 120-277V120V277V347V
- Integral EmergencyEM Integral
- Lumen Maintenance102000 h
- CertificatesUL/CULMade in USA
- EnvironmentWet
- Mounting TypeCeiling RecessedDrywallT-Grid Ceiling
- HousingNew Construction
- Housing Depth7 1/4 ''
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
Lead timeEPD-6ADJ
Cost
—
CONFIGURATORDESCRIPTIONDIMENSIONSLIGHT SOURCEWATT/LUMENSPOWER/CONTROLSYou reconfigured the product. To remove this message please update you custom description.Marks unavailable product configuration, refer to manufacturer’s documentation for details
BUILD CATALOG NUMBER
