SPR-CLPH2-DL9. Spredlite High Lumen Baffle Cove Mounted LED Enhanced Shielding Wallgrazer.
Configure
Add to project
RESOURCES
DESCRIPTION
Spredlite is a unique wallgrazing system that preserves iconic architecture by draping light fully and evenly over textured or polished surfaces up to 40’ high.
– Spredlite Cross Baffles provide a 30° shielding angle, eliminating reflections and bright spots; in contrast, flat baffles produce glare at many angles
– Each modular segment provides lockable 0°-10° tilt
– Special applications include curved wall and recessed
– Notable Installations: MoMA, Kimbell Art Museum, London U.S. Embassy, MetLife Building
– Spredlite Cross Baffles provide a 30° shielding angle, eliminating reflections and bright spots; in contrast, flat baffles produce glare at many angles
– Each modular segment provides lockable 0°-10° tilt
– Special applications include curved wall and recessed
– Notable Installations: MoMA, Kimbell Art Museum, London U.S. Embassy, MetLife Building
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 5 1/2"L: 18"27"36"45"Run length (Ft)H: 8 1/4"
- Light SourceLED
- CCT/Color2700K3000K3500K4000K5000K
- CRI92 80
- Watt(Approx)25 W
- Lumens(Approx)1558 Lm1791 Lm
- OpticsDirectGrazing
- AdjustableLock Aiming
- DimmingDim to 1%Dim to <1%0-10VeldoLED SOLO DALIeldoLED SOLO 0-10V
- Controls/Network
- Power/VoltageIntegral120V277V
- Integral Emergency
- Lumen Maintenance
- CertificatesCSAMade in USA
- EnvironmentDamp
- Mounting TypeSurface
- Housing
- Housing Depth
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
