Edison Lighting Group
ED CURVES + RECESSED.
Configure
Add to project
RESOURCES
DESCRIPTION
- Architectural curved system with direct lighting distribution.
- Light source: LED boards.
- Diffused illumination is provided by high efficiency frosted opal lens or by optional prismatic optic.
- Sleek body of the luminaire is made from aluminum profile curved to desired shape.
- Suitable for non-insulated recessed installations.
- Extruded aluminum body comes with black or white finish.
- Available with custom color options or unique shape configurations.
- LED Strips are rated for 60,000hrs. L80 with +90 CRI.
- Has a proven record in office, commercial and retail installations.
- Custom modifications are available.
- ED luminaires are certified to CSA and UL Standards.
- Specification Sheet
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 3.15"L: Run length (Ft)
- Light SourceLED
- CCT/Color3000K3500K4000KTunable WhiteRGBW
- CRI90
- Watt(Approx)5 W7 W10 W
- Lumens(Approx)535 Lm750 Lm1080 Lm
- OpticsDirectGeneral Diffused
- Adjustable
- DimmingDim to 3-10%Dim to 1%Non-Dim0-10VDALIDMX
- Controls/NetworkBluetoothWireless DimmingCasambi
- Power/VoltageIntegralUNV 120-277V347V
- Integral Emergency
- Lumen Maintenance60000 h
- CertificatesETLDeclare
- Environment
- Mounting TypeCeiling RecessedDrywall
- HousingNew Construction
- Housing Depth2.95 ''
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
Lead timeED-CURVES-PL-REC
Cost
—
CONFIGURATORDESCRIPTIONDIMENSIONSLIGHT SOURCEWATT/LUMENSPOWER/CONTROLSYou reconfigured the product. To remove this message please update you custom description.Marks unavailable product configuration, refer to manufacturer’s documentation for details
BUILD CATALOG NUMBER
