Edison Lighting Group
ED RING+.
Configure
Add to project
RESOURCES
-
SPEC SHEET
-
WHERE TO BUY
-
MANUFACTURER'S PAGE
-
ASK MANUFACTURER
DESCRIPTION
- Architectural luminaire with direct or direct-indirect distribution.
- Light source: LED board (5.5"/11"/22"/24").
- Diffused illumination is provided by high efficiency frosted opal lens.
- Sleek body of the luminaire combines two aluminum side with laser cut metal top enclosure.
- Suitable for suspended and wall mounted installations.
- Extruded aluminum body comes with white, black or grey finishes.
- Also available with custom color options or vinyl decals.
- LED Strips are rated for 60,000hrs. L80 with +85 CRI.
- Has a proven record in office, commercial and retail installations.
- Custom modifications are available.
- ED luminaires are certified to CSA and UL Standards.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 23.6"35.4"47.2"L: 23.6"35.4"47.2"Run length (Ft)H: 2.55"
- Light SourceLED
- CCT/Color3000K3500K4000KTunable White
- CRI90
- Watt(Approx)25 W50 W75 W
- Lumens(Approx)2295 Lm4590 Lm6890 Lm
- OpticsDirectDirect/IndirectGeneral Diffused
- Adjustable
- DimmingDim to 3-10%Dim to 1%0-10VDALI
- Controls/NetworkBluetooth
- Power/VoltageIntegral120V277V347V
- Integral Emergency
- Lumen Maintenance60000 h
- CertificatesUL/CULDeclare
- EnvironmentDamp
- Mounting TypePendantCeiling SurfaceWall Surface
- Housing
- Housing Depth
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
Lead timeEDRING
Cost
—
CONFIGURATORDESCRIPTIONDIMENSIONSLIGHT SOURCEWATT/LUMENSPOWER/CONTROLSYou reconfigured the product. To remove this message please update you custom description.Marks unavailable product configuration, refer to manufacturer’s documentation for details
BUILD CATALOG NUMBER
