- Architectural acoustic luminaire with direct lighting distribution.
- Light source: COB LED.
- High-efficiency integral reflector combined with opal lens insert provides excellent lighting distribution.
- Extruded aluminum body comes with a black or white finish.
- Removable fin-shaped Eco-Felt Baffles are attached to the top and face plate.
- Available in two standard sizes with various baffle shapes.
- Class 1 fire rated with 0.7 Noise Reduction Coefficient/1” Acoustic.
- LED spot is rated for 60,000 hrs. L70 with +90 CRI.
- Suitable for suspended installations.
- Custom finishes and modifications are available.
- ED luminaires are certified to CSA and UL standards
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 24"L: 24"H: 15.75"
- Light SourceLED
- CCT/Color3000K3500K4000K
- CRI90
- Watt(Approx)10 W15 W20 W
- Lumens(Approx)990 Lm1475 Lm1940 Lm
- OpticsDirectGeneral Diffused
- Adjustable
- DimmingDim to 3-10%Dim to 1%Non-Dim0-10VDALI
- Controls/NetworkBluetooth
- Power/VoltageIntegralUNV 120-277V
- Integral Emergency
- Lumen Maintenance60000 h
- CertificatesETLDeclare
- EnvironmentAcoustic Absorption
- Mounting TypePendant
- Housing
- Housing Depth
