FC Lighting
FCSL101. Exterior Die-Cast Brick Light with Die-Cast Faceplate.
 Configure
 Add to project
FC Lighting. FCSL101. Exterior Die-Cast Brick Light with Die-Cast Faceplate.
FC Lighting. FCSL101. Exterior Die-Cast Brick Light with Die-Cast Faceplate.
FC Lighting. FCSL101. Exterior Die-Cast Brick Light with Die-Cast Faceplate.
FC Lighting. FCSL101. Exterior Die-Cast Brick Light with Die-Cast Faceplate.
RESOURCES
DESCRIPTION
The FCSL101 Step Light is U.L. listed for interior and exterior wet locations. Housing and faceplates are marine grade, corrosion resistant, heavy walled, high pressure die cast aluminum construction with (2) 7/8″ KO. Lens is 1/8″ thick, tempered opal, heat resistant glass. Precision formed, reflector for maximum reflectance. Standard polyester powder coat finishes include black, bronze, silver and white with custom or RAL colors also available.
MORE DESCRIPTION
SPECIFICATIONS
  • Dimensions
    L: 9.44"
    H: 2.8"
  • Light Source
    LED
  • CCT/Color
    2700K3000K3500K4000K
  • CRI
    85
  • Watt(Approx)
    10 W
  • Lumens(Approx)
    450 Lm
  • Optics
    DirectGeneral Diffused
  • Adjustable
  • Dimming
    Dim to 3-10%0-10V
  • Controls/Network
  • Power/Voltage
    IntegralUNV 120-277V120V277V
  • Integral Emergency
  • Lumen Maintenance
    70000 h
  • Certificates
    ETLADA
  • Environment
    IP65Corrosion Resistant
  • Mounting Type
    Wall RecessedConcreteStone/Tile
  • Housing
  • Housing Depth
 SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
