Focal Point (Legrand)
FLC3D. ID+ 3.5'' OVERLAP & TRIMLESS LED DOWNLIGHTS - WARM DIM.
Configure
Add to project
RESOURCES
DESCRIPTION
Design
Shallow 2.6" housing.
Self-flanged Clear Diffuse reflector cone features superior brightness control.
Die-cast, super short trim available.
Die-cast heat sink designed for maximum thermal dissipation.
Companion to ID+ 3.5" Cylinder family with matching aperture size.
Performance
Beam spreads from 25° to 90°.
50-degree cut-off trim for optimal visual comfort and 60-degree or 75-degree cut-off trim for very shallow plenums and variety of beam spreads.
Standard lumen outputs from 700 to 2100.
80, 90, 97 CRI.
Selection of dimming drivers including 0-10V, DALI, Lutron and forward phase.
Two warm dim spectra mimic the black body curves of halogen and incandescent light sources.
Three tunable white CCT ranges help support human activity, well-being, and preferences.
Standard white light temperatures from 2700K to 4000K.
Application
Designed for general downlighting in residential, commercial, retail and hospitality applications.
High lumen outputs support high ceiling applications.
Ideal for shallow or restricted plenums.
Shallow 2.6" housing.
Self-flanged Clear Diffuse reflector cone features superior brightness control.
Die-cast, super short trim available.
Die-cast heat sink designed for maximum thermal dissipation.
Companion to ID+ 3.5" Cylinder family with matching aperture size.
Performance
Beam spreads from 25° to 90°.
50-degree cut-off trim for optimal visual comfort and 60-degree or 75-degree cut-off trim for very shallow plenums and variety of beam spreads.
Standard lumen outputs from 700 to 2100.
80, 90, 97 CRI.
Selection of dimming drivers including 0-10V, DALI, Lutron and forward phase.
Two warm dim spectra mimic the black body curves of halogen and incandescent light sources.
Three tunable white CCT ranges help support human activity, well-being, and preferences.
Standard white light temperatures from 2700K to 4000K.
Application
Designed for general downlighting in residential, commercial, retail and hospitality applications.
High lumen outputs support high ceiling applications.
Ideal for shallow or restricted plenums.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 4.5"L: 4.5"
- Light SourceLED
- CCT/Color2700K Dim to Warm3000K Dim to Warm
- CRI90
- Watt(Approx)25 W
- Lumens(Approx)1555 Lm
- OpticsDirectMediumFloodWide Flood
- Adjustable
- DimmingDim to 3-10%Dim to 1%Dim to <1%TRIAC/Forward/Leading0-10VDALILutron Hi-lume EcoSystem (LDE1)
- Controls/Network
- Power/VoltageIntegral120V277V
- Integral Emergency
- Lumen Maintenance55000 h
- CertificatesUL/CULEnergy Star*Declare
- EnvironmentWet
- Mounting TypeCeiling RecessedDrywallT-Grid Ceiling
- HousingChicago PlenumAir Tight
- Housing Depth2.64 ''3 ''3.53 ''3.09 ''
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
