Hadco (Signify)
RSC2. Step light Landscape.
Configure
Add to project



RESOURCES
DESCRIPTION
The RSC2 is a line voltage step light perfect for high pedestrian traffic and plant life applications. It is available in standard sources including CFL along with high brightness LED sources. It is available with a die-cast aluminum and bronze construction with low copper to resist corrosion. The cast bronze louver is natural cast bronze with frosted tempered glass. The die-cast copper-free aluminum louver has a 45° cutoff with frosted tempered glass with silicone gasketing. Available in three colors plus natural bronze. Symmetric Reflector is precision formed with a white reflective coating. The cast louver offers lower light levels with cut-off for lighting stairways or general lighting where shielding of the light source is more important than high light levels.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsL: 9"H: 3 1/2"
- Light SourceLED
- CCT/Color3000K4000K
- CRI80
- Watt(Approx)2.7 W4.3 W6.1 W8 W10.6 W
- Lumens(Approx)46 Lm85 Lm45 Lm83 Lm122 Lm158 Lm179 Lm119 Lm154 Lm175 Lm
- OpticsDirectGeneral Diffused
- Adjustable
- DimmingDim to 3-10%0-10V
- Controls/Network
- Power/VoltageIntegralUNV 120-277V
- Integral Emergency
- Lumen Maintenance50000 h
- CertificatesETL
- EnvironmentWetCorrosion Resistant
- Mounting TypeWall RecessedConcreteStone/Tile
- Housing
- Housing Depth
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
RSC2
—
CONFIGURATORDESCRIPTIONDIMENSIONSLIGHT SOURCEWATT/LUMENSPOWER/CONTROLSYou reconfigured the product. To remove this message please update you custom description.Marks unavailable product configuration, refer to manufacturer’s documentation for detailsBUILD CATALOG NUMBER
