H. E. Williams, Inc.
AST1. PoE Tunable White Architectural Surface - Curved Floating Center.
Configure
Add to project
DESCRIPTION
- Backlit curved lens provides uniform illumination for visual comfort.
- Curved floating center detail creates a highly-aesthetic presence.
- Hinged door frame with optical assembly swings down to allow easy access from room side of fixture.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 1 Ft2 FtL: 2 Ft4 FtH: 3 13/16"
- Light SourceLED
- CCT/Color2700K3000K3500K4000K5000KTunable White
- CRI80 90
- Watt(Approx)14.4 W23.2 W21.7 W46.9 W47.5 W81.2 W
- Lumens(Approx)1649 Lm2600 Lm2506 Lm2743 Lm5240 Lm5802 Lm10049 Lm
- OpticsDirectGeneral Diffused
- Adjustable
- Dimming
- Controls/NetworkEthernet
- Power/VoltagePoE
- Integral Emergency
- Lumen Maintenance50000 h
- CertificatesCSAMade in USABAA
- EnvironmentAntimicrobial FinishDamp
- Mounting TypeCeiling Surface
- Housing
- Housing Depth
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
Lead timeAST1-POE
Cost
—
CONFIGURATORDESCRIPTIONDIMENSIONSLIGHT SOURCEWATT/LUMENSPOWER/CONTROLSYou reconfigured the product. To remove this message please update you custom description.Marks unavailable product configuration, refer to manufacturer’s documentation for details
BUILD CATALOG NUMBER
