H. E. Williams, Inc.
CW. LED Contour Wall.
 Configure
 Add to project
H. E. Williams, Inc.. CW. LED Contour Wall.
H. E. Williams, Inc.. CW. LED Contour Wall.
H. E. Williams, Inc.. CW. LED Contour Wall.
RESOURCES
DESCRIPTION
  • Contoured architectural form integrates seamlessly with modern interiors
  • Low-profile style meets ADA compliance standards
  • Direct and indirect lighting with closed top or bottom options available
  • Tamper-resistant screws are provided for vandal-prone areas
  • Support human-centric design with adaptive, individualized lighting using tunable white light
  • Low-voltage controller wall plate accessories provide easy access for healthcare personnel
  • Six standard finish options and a wide selection of custom colors complement architectural elements
  • Support human-centric design with adaptive, individualized lighting using tunable white light
  • Build America, Buy America and Buy American Act compliant
  • Wireless in-fixture control solutions available
  • Made Right Here® in the USA
MORE DESCRIPTION
SPECIFICATIONS
  • Dimensions
    W: 2 5/8"
    L: 2 Ft3 Ft4 Ft
    H: 6 1/2"
  • Light Source
    LED
  • CCT/Color
    2700K3000K3500K4000K5000K
  • CRI
    80 90
  • Watt(Approx)
    20.8 W32.2 W31.4 W42.7 W47.6 W41.4 W64.4 W63.7 W84.8 W
  • Lumens(Approx)
    2559 Lm3859 Lm3722 Lm5008 Lm5644 Lm5118 Lm7509 Lm10016 Lm
  • Optics
    DirectGeneral Diffused
  • Adjustable
  • Dimming
    Dim to 3-10%Dim to 1%TRIAC/Forward/LeadingELV/Reverse/Trailing0-10V
  • Controls/Network
  • Power/Voltage
    IntegralUNV 120-277V120V277V347V
  • Integral Emergency
    EM Integral
  • Lumen Maintenance
    72000 h
  • Certificates
    CSAMade in USAADABAA
  • Environment
    Damp
  • Mounting Type
    Wall Surface
  • Housing
  • Housing Depth
 SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
