H. E. Williams, Inc.
GH. LED Compact Modular High Bay.
Configure
Add to project
RESOURCES
DESCRIPTION
- Scalable design up to 72,000 lumens
- Optimized for single-person installation
- Multiple shielding and distribution options
- HE option delivers superior efficacies up to 187 lm/W
- Frosted lens reduces glare
- Energy-saving alternative designed to replace traditional HID or fluorescent high bays
- Variety of mounting options for surface and suspended applications
- All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion
- DLC Compliant
- Build America, Buy America and Buy American Act compliant
- Wireless in-fixture control solutions available
- Made Right Here® in the USA
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 17 5/8"L: 2 Ft4 FtH: 3 5/8"
- Light SourceLED
- CCT/Color3000K3500K4000K5000K
- CRI80 90
- Watt(Approx)55.9 W79.4 W125.9 W177.9 W215.8 W272.6 W293.2 W327.9 W372.2 W429.8 W495.9 W539.7 W
- Lumens(Approx)8075 Lm12246 Lm18009 Lm23510 Lm31210 Lm35765 Lm40295 Lm48002 Lm54031 Lm61173 Lm66420 Lm72181 Lm
- OpticsDirectNarrowGeneral Diffused
- Adjustable
- DimmingDim to 3-10%Non-Dim0-10V
- Controls/Network
- Power/VoltageIntegralUNV 120-277V120V208V220-240V277V347V480V
- Integral EmergencyEM Integral
- Lumen Maintenance65000 h
- CertificatesCSAMade in USADLC*BAA
- EnvironmentDamp
- Mounting TypePendantSurface
- Housing
- Housing Depth
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
Lead timeGH
Cost
—
CONFIGURATORDESCRIPTIONDIMENSIONSLIGHT SOURCEWATT/LUMENSPOWER/CONTROLSYou reconfigured the product. To remove this message please update you custom description.Marks unavailable product configuration, refer to manufacturer’s documentation for details
BUILD CATALOG NUMBER
