Holophane (Acuity Brands Lighting)
PUCL3. Utility Taft Series Luminaire Full Cutoff LED3.
Configure
Add to project




RESOURCES
DESCRIPTION
The PUCL3 Post-top LED lantern is designed to meet the IESNA requirements for zero-uplight classification and reduced impact on urban sky glow. It offers a wide range of distributions and lumen packages with multiple optical configurations to balance performance and visual comfort to your specific needs. The PUCL3 is a utility-friendly, feature-rich solution providing lighting designers with a high level of design flexibility in color temperature and optical distribution choices. Controls options from our DTL® and nLight® AIR brands range from dusk-to-dawn switching all the way through occupancy sensors or even wireless network controls. Available in multiple color choices with a variety of finial options.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 17"L: 17"H: 34"
- Light SourceLED
- CCT/Color2700K3000K4000K
- CRI70
- Watt(Approx)30 W39 W48 W59 W69 W81 W91 W98 W107 W117 W130 W
- Lumens(Approx)4398 Lm5706 Lm6997 Lm8763 Lm10185 Lm11456 Lm12548 Lm13414 Lm14623 Lm15716 Lm16904 Lm
- OpticsDirectType IIType IIIType IVType V
- Adjustable
- DimmingDim to 3-10%0-10V
- Controls/NetworkIntegral Sensor
- Power/VoltageIntegralUNV 120-277V277VUNC 347-480V
- Integral Emergency
- Lumen Maintenance100000 h
- CertificatesUL/CULDLC*RoHSBAA
- EnvironmentIP65
- Mounting TypePole/Post Top
- Housing
- Housing Depth
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
