Holophane (Acuity Inc.)
VL. Vantage LED High Bay.
Configure
Add to project




RESOURCES
DESCRIPTION
The Vantage LED luminaire exceeds rigorous demands of food-processing plants and related areas, thanks to its strategic sloped shape and ultra-sleek corrosion-resistant finish that repel water and provide nowhere for food, dirt or debris to hide. Choose either prismatic acrylic or polycarbonate lens which stand up to chemicals used in food-processing plants and similar applications. Meets stringent requirements IP66, IP67, IP69, and NSF Splash Zone 2. Over 250 configurations are DLC Standard or DLC Premium qualified products. Vantage is the optimal solution to meet code and qualify for possible rebates. Energy-saving control options for all applications including 0-10V dimming standard, NSF approved occupancy sensor and wireless control options for zones, and scheduling. Control a single fixture or entire space. Available with nLight® AIR and IOTA ETS Emergency Control Device.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 20.62"L: 20.62"H: 17.62"
- Light SourceLED
- CCT/Color3000K4000K5000K
- CRI70 80 90
- Watt(Approx)82 W105 W128 W180 W221 W260 W
- Lumens(Approx)12832 Lm15592 Lm19260 Lm24548 Lm32015 Lm37782 Lm
- OpticsDirectWide Flood
- Adjustable
- DimmingDim to 3-10%0-10V
- Controls/NetworknLight®Integral Sensor
- Power/VoltageIntegralUNV 120-277V120V208V220-240V277VUNC 347-480V347V480V
- Integral Emergency
- Lumen Maintenance100000 h
- CertificatesUL/CULDLC*NSF
- EnvironmentHazardousFood ProcessingIP69K High-Pressure/Steam-Jet Cleaning
- Mounting TypePendantCeiling Surface
- Housing
- Housing Depth
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
