Invue (Cooper Lighting Solutions)
EMM2. Epic Decorative Pendant Luminaire.
Configure
Add to project




RESOURCES
DESCRIPTION
The Epic pendant luminaire enhances its surroundings with a wide array of stunning dayform configurations. Combining adaptable aesthetics with easy installation and maintenance, Epic’s thoughtful, inspired design will delight architects, installers and residents wherever it is used. New optical configurations are also available, with higher maximum output in either discrete or visual comfort light engines. Whether you need precision optical control for maximum uniformity, spacing and efficiency, or visual comfort options with a fully luminous surface, Epic delivers superior layouts resulting in enhanced user experiences.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 18.383"19.26"24.408"L: 18.383"19.26"24.408"H: 9"15.5"
- Light SourceLED
- CCT/Color2400K or less2700K3000K3500K4000K5000KYellow/Amber
- CRI70 80
- Watt(Approx)28 W33 W39 W44 W49 W61 W59 W90 W78 W101 W113 W134 W106 W130 W156 W170 W
- Lumens(Approx)3421 Lm4747 Lm5146 Lm6495 Lm5872 Lm9700 Lm7162 Lm9023 Lm13333 Lm14283 Lm11772 Lm17527 Lm19807 Lm15560 Lm18250 Lm19908 Lm
- OpticsDirectMediumWide FloodType IType IIType IIIType IVType V
- Adjustable
- DimmingDim to 3-10%DALI
- Controls/NetworkBluetoothWaveLinxIntegral Sensor
- Power/VoltageIntegralUNV 120-277V277VUNC 347-480V347V480V
- Integral Emergency
- Lumen Maintenance102000 h
- CertificatesUL/CULDark SkyRoHSBAA
- EnvironmentIP66
- Mounting TypePole/Mast ArmPendantWall Arm/Cantilever
- Housing
- Housing Depth
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
EMM2
—
CONFIGURATORDESCRIPTIONDIMENSIONSLIGHT SOURCEWATT/LUMENSPOWER/CONTROLSYou reconfigured the product. To remove this message please update you custom description.Marks unavailable product configuration, refer to manufacturer’s documentation for detailsBUILD CATALOG NUMBER
