LLI-MCF. MICRO FLANGED EXTRUSION + LED TAPELIGHT.
Configure
Add to project
RESOURCES
DESCRIPTION
Accommodates tapelights up to 0.20″ (5mm) wide.
Silver anodized finish
Frosted lens
Dimensions: W 0.55″ x H 0.35″
Silver anodized finish
Frosted lens
Dimensions: W 0.55″ x H 0.35″
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 0.55"L: Run length (inch)H: 0.35"
- Light SourceLED
- CCT/Color2700K3000K3500K4000K5000K
- CRI90
- Watt(Approx)3 W/Ft2.5 W/Ft4 W/Ft
- Lumens(Approx)135 Lm/Ft176 Lm/Ft189 Lm/Ft
- OpticsDirectGeneral Diffused
- Adjustable
- DimmingDim to 3-10%Dim to <1%Non-DimTRIAC/Forward/Leading0-10VLutron Hi-lume Premier Eco (L3D0E)
- Controls/Network
- Power/VoltageRemoteUNV 120-277V120V277V
- Integral Emergency
- Lumen Maintenance
- CertificatesUL/CUL
- Environment
- Mounting TypeSurface
- Housing
- Housing Depth
