Lumec (Genlyte Solutions)
GPLS. RoadStar Roadway (small).
Configure
Add to project




RESOURCES
DESCRIPTION
Stand out from the crowd with a striking design statement. Lumec outdoor luminaires embody the epitome of sophisticated aesthetics, precision engineering and uncompromising quality, and the next generation Lumec RoadStar LED architectural roadway luminaires are no exception. With two luminaire sizes and a wide range of options, RoadStar luminaires create an unrivaled crossroad of artistic style and high-performance functionality, so your design can make a powerful impact in any outdoor area.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 13 1/4"L: 28 1/2"H: 4 3/4"
- Light SourceLED
- CCT/Color3000K4000K
- CRI70
- Watt(Approx)27 W38 W55 W53 W71 W78 W110 W107 W161 W
- Lumens(Approx)4102 Lm4027 Lm5160 Lm5066 Lm6940 Lm7069 Lm8176 Lm8027 Lm10269 Lm13983 Lm12221 Lm10083 Lm13728 Lm11998 Lm15318 Lm15039 Lm20705 Lm20328 Lm
- OpticsDirectType IIType IIIType IVType V
- Adjustable
- DimmingDim to 3-10%0-10V
- Controls/NetworkIntegral Sensor
- Power/VoltageIntegralUNV 120-277V277VUNC 347-480V480V
- Integral Emergency
- Lumen Maintenance100000 h
- CertificatesUL/CULDLC*
- EnvironmentIP66
- Mounting TypePole/Mast Arm
- Housing
- Housing Depth
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
Lead timeGPLS-G3
—
