Luminis (Acuity Brands Lighting)
CL642. Lumistik Ø6'' pendant with acrylic diffuser.
Configure
Add to project
RESOURCES
DESCRIPTION
CL642 is a Ø6" pendant with a high impact white translucent acrylic diffuser. Optional downlight module. It delivers up to 10,000 lumens.
Lumistik pendants, available with stem, cable or catenary mount, are suited for interior and exterior applications where public space enhancement is the goal. The LED is contained in a white UV stabilized high impact acrylic sealed cylinder, designed to provide uniform illumination. Luminaires are available with white or color changing RGBW. An optional downlight component is available. They are rated IP65 for exterior wet locations.
Lumistik pendants, available with stem, cable or catenary mount, are suited for interior and exterior applications where public space enhancement is the goal. The LED is contained in a white UV stabilized high impact acrylic sealed cylinder, designed to provide uniform illumination. Luminaires are available with white or color changing RGBW. An optional downlight component is available. They are rated IP65 for exterior wet locations.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 6"L: 6"H: 37.3"
- Light SourceLED
- CCT/Color2700K3000K3500K4000KRGBW
- CRI80
- Watt(Approx)20 W37 W54 W71 W82 W101 W
- Lumens(Approx)2217 Lm4035 Lm4158 Lm5757 Lm8352 Lm10029 Lm
- OpticsDirectNarrowFloodWide Flood
- Adjustable
- DimmingDim to 3-10%0-10V
- Controls/NetworknLight®
- Power/VoltageIntegralUNV 120-277V120V277VUNC 347-480V347V480V
- Integral EmergencyEM Integral
- Lumen Maintenance60000 h
- CertificatesUL/CUL
- EnvironmentIP65MarineCorrosion Resistant
- Mounting TypePendantCatenary
- Housing
- Housing Depth
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
Lead timeCL642
Cost
—
CONFIGURATORDESCRIPTIONDIMENSIONSLIGHT SOURCEWATT/LUMENSPOWER/CONTROLSYou reconfigured the product. To remove this message please update you custom description.Marks unavailable product configuration, refer to manufacturer’s documentation for details
BUILD CATALOG NUMBER
