Lithonia Lighting (Acuity Brands Lighting)
ENVX. ENVEX Series LED Tunable White DC2DC 1'x4', 2'x2' and 2'x4'.
Configure
Add to project
RESOURCES
DESCRIPTION
ENVEX™ is a high-performance recessed ambient series designed to meet intense specification requirements with ease. The timeless design allows ENVEX to enrich any space without distracting from the beauty of the architecture. Offering a wide range of lumen packages, color temperatures, and lighting controls options to meet specifications with ease, ENVEX is available in both Static White and Tunable White, delivering up to 7200 lumens at a color quality of up to 90CRI.
ENVEX is available in two designs, both offering volumetric distribution. Each fully-luminous design is visually comfortable for occupants, making ENVEX a perfect solution for commercial spaces where occupant efficiency is key such as schools, offices, and healthcare.
ENVEX™ is compatible with the DC2DC architecture
ENVEX is available in two designs, both offering volumetric distribution. Each fully-luminous design is visually comfortable for occupants, making ENVEX a perfect solution for commercial spaces where occupant efficiency is key such as schools, offices, and healthcare.
ENVEX™ is compatible with the DC2DC architecture
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 1'2'L: 2'4'
- Light SourceLED
- CCT/ColorTunable White
- CRI90
- Watt(Approx)16.5 W21.9 W20.2 W29 W36.3 W36.9 W42.9 W40.2 W
- Lumens(Approx)1543 Lm2044 Lm2017 Lm3445 Lm3136 Lm3670 Lm4241 Lm4342 Lm
- OpticsDirectGeneral Diffused
- Adjustable
- DimmingDim to 3-10%DALI
- Controls/Network
- Power/VoltageRemoteUNV 120-277V
- Integral Emergency
- Lumen Maintenance60000 h
- CertificatesCSA
- EnvironmentClean RoomAntimicrobial FinishDamp
- Mounting TypeCeiling RecessedT-Grid Ceiling
- HousingIC
- Housing Depth3.125 ''3.625 ''
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
Lead timeENVX-TW-DC2DC
Cost
—
CONFIGURATORDESCRIPTIONDIMENSIONSLIGHT SOURCEWATT/LUMENSPOWER/CONTROLSYou reconfigured the product. To remove this message please update you custom description.Marks unavailable product configuration, refer to manufacturer’s documentation for details
BUILD CATALOG NUMBER
