UV8. BLACKLIGHT SERIES LED.
Configure
Add to project
RESOURCES
DESCRIPTION
The UV8 Blacklight Series creates a powerful, tight beam for special effects and themed environments.
The UV8 is a portable LED blacklight that can produces a range of beam spreads from a high intensity spot to a flood with supplied reflectors. The luminaire uses high efficiency UV LEDs to produce a 2550mW output of ultraviolet energy tuned to narrow 365nm peak wavelength at only 15 watts. 8°, 15°, 25°, 40°, and 60° beam spread reflectors are included. The absence of visible light is achieved without the use of a special filter. The LEDs have a lifetime of 25,000 hours at L70.
The UV8 Series can be used with our versatile CONTROLTrack™ system to be controlled with either 0-10V or DMX protocols and dimmable to 1%. The LSI CONTROLTrack™ option allows for unparalleled flexibility for controlling an entire track run or individual fixtures from a simple wall device, all the way through the most sophisticated control systems.
COB LED panel and driver are field replaceable.
The UV8 is a portable LED blacklight that can produces a range of beam spreads from a high intensity spot to a flood with supplied reflectors. The luminaire uses high efficiency UV LEDs to produce a 2550mW output of ultraviolet energy tuned to narrow 365nm peak wavelength at only 15 watts. 8°, 15°, 25°, 40°, and 60° beam spread reflectors are included. The absence of visible light is achieved without the use of a special filter. The LEDs have a lifetime of 25,000 hours at L70.
The UV8 Series can be used with our versatile CONTROLTrack™ system to be controlled with either 0-10V or DMX protocols and dimmable to 1%. The LSI CONTROLTrack™ option allows for unparalleled flexibility for controlling an entire track run or individual fixtures from a simple wall device, all the way through the most sophisticated control systems.
COB LED panel and driver are field replaceable.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 5 7/8"L: 5 7/8"H: 6 9/16"
- Light SourceLED
- CCT/Color
- CRI
- Watt(Approx)15 W
- Lumens(Approx)
- OpticsDirectNarrowMediumFloodWide Flood
- AdjustableAdjustable
- DimmingDim to 3-10%Dim to 1%ELV/Reverse/TrailingDMX
- Controls/Network
- Power/VoltageIntegral120V220-240V
- Integral Emergency
- Lumen Maintenance
- Certificates
- Environment
- Mounting TypeCeiling SurfaceClamp
- Housing
- Housing Depth
