Mark Architectural Lighting (Acuity Brands Lighting)
MCV102. MARKCOVE 102 Static White & Color.
Configure
Add to project
RESOURCES
DESCRIPTION
- Low profile
- Extruded aluminum construction
- Static White outputs: 250, 400, 600, 800 or 1000 lumens per foot
- Static White CCT: 2700, 3000, 3500, 4000 or 5000K
- Static color hues: Red, Green, Blue or Amber
- Cove optics: 120x120
- 0-10V, nLight or nLightAIR2
- Flicker free dimming to DARK (0.01%)
- Shielding options: frosted lens, linear cross baffle, hex cell louver, glare visor
- Mounting: surface fixed, surface adjustable
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 1 1/2"L: 1 Ft4 FtRun length (Ft)H: 1 3/8"
- Light SourceLED
- CCT/Color2700K3000K3500K4000K5000KYellow/AmberRedGreenBlue
- CRI80 90
- Watt(Approx)2.4 W/Ft3.5 W/Ft4.2 W/Ft5.0 W/Ft5.7 W/Ft6.5 W/Ft7.4 W/Ft8.2 W/Ft
- Lumens(Approx)243 Lm/Ft400 Lm/Ft481 Lm/Ft575 Lm/Ft660 Lm/Ft754 Lm/Ft839 Lm/Ft944 Lm/Ft
- OpticsDirectWide Flood
- AdjustableAdjustable
- DimmingDim to 1%Dim to <1%ELV/Reverse/Trailing0-10V
- Controls/NetworknLight®
- Power/VoltageIntegralRemoteUNV 120-277V120V347V
- Integral Emergency
- Lumen Maintenance54000 h
- CertificatesCSAMade in USABAA
- EnvironmentDamp
- Mounting TypeWall Arm/CantileverSurface
- Housing
- Housing Depth
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
Lead timeMCV102-STWH
Cost
—
CONFIGURATORDESCRIPTIONDIMENSIONSLIGHT SOURCEWATT/LUMENSPOWER/CONTROLSYou reconfigured the product. To remove this message please update you custom description.Marks unavailable product configuration, refer to manufacturer’s documentation for details
BUILD CATALOG NUMBER
