Mark Architectural Lighting (Acuity Brands Lighting)
SL1LP. Slot 1 Recessed Patterns Tunable White.
 Configure
 Add to project
Mark Architectural. SL1LP-TUWH. SLOT 1 Recessed Pattern Linear with Static White and Tunable White.
Mark Architectural. SL1LP-TUWH. SLOT 1 Recessed Pattern Linear with Static White and Tunable White.
Mark Architectural. SL1LP-TUWH. SLOT 1 Recessed Pattern Linear with Static White and Tunable White.
Mark Architectural. SL1LP-TUWH. SLOT 1 Recessed Pattern Linear with Static White and Tunable White.
RESOURCES
DESCRIPTION
  • 200 to 1000 lumens per foot
  • Up to 119 lumens per watt
  • Flush or regressed lens
  • Multiple lens treatment options include drop and edge view
  • Powered and controlled by Modulus Remote Driver kit that combines all power and control system inputs into a single feed cord.
  • Flicker free dimming to dark (0.01%) enabled by Modulus power and control architecture with integrated digital nLight® module for system networking
  • Total System Integration features 5-year limited warranty by Acuity Brands, covers all components and construction
  • Pre-configured square andrectangular patterns available in 2' and 4' bases, up to 8'. Ability to create a custom pattern to meet any specification.
  • Mainstream Dynamic White, with nTune technology offers full range tunability from 2700K to 6500K
MORE DESCRIPTION
SPECIFICATIONS
  • Dimensions
    W: 3"
    L: Run length (Ft)
    H: 1/2"1"1 1/2"
  • Light Source
    LED
  • CCT/Color
    Tunable White
  • CRI
    80
  • Watt(Approx)
    1.67 W/Ft3.38 W/Ft5.3 W/Ft7.55 W/Ft9.77 W/Ftcustom
  • Lumens(Approx)
    185 Lm/Ft402 Lm/Ft615 Lm/Ft840 Lm/Ft1030 Lm/Ftcustom
  • Optics
    DirectGeneral Diffused
  • Adjustable
  • Dimming
    Dim to <1%0-10V
  • Controls/Network
    nLight®Integral Sensor
  • Power/Voltage
    IntegralUNV 120-277V120V277V347V
  • Integral Emergency
  • Lumen Maintenance
    60000 h
  • Certificates
    UL/CULRoHSDeclare
  • Environment
    Damp
  • Mounting Type
    Ceiling RecessedDrywallTrimless DrywallT-Grid CeilingSlot T-Grid Ceiling
  • Housing
    ICChicago Plenum
  • Housing Depth
    3 3/8 ''
 SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
