Metalux (Cooper Lighting Solutions)
APVT-S. 4' and 8' Industrial Vaportite CCT and Lumen Select.
Configure
Add to project
RESOURCES
DESCRIPTION
- Selectable CCT (3500/4000/5000K) and Lumen select for greater flexibility
- Two sizes in stock: 4ft - 3/4.5/8,000 and 8ft - 8/10/12,000 lumen
- Durable polycarbonate housing with integral metal gear tray
- High Impact IK08 optical lens and light engine enclosure
- Stainless steel latches, single conduit hub, and mounting included
- Multi-volt 120-277V input, 0-10V dimming driver
- High-Performance efficacy up to 147 lm/W
- UL wet location and IP65 rated
- DLC qualified
- 5-year limited warranty
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 4"L: 47 1/4"93 15/16"H: 3 5/8"
- Light SourceLED
- CCT/Color3500K4000K5000KField Select CCT
- CRI80
- Watt(Approx)21-22 W32-33 W45-47 W59-60 W78 W92-94 Wswitchable
- Lumens(Approx)2977-3138 Lm4242-4620 Lm5531-6254 Lm8379-8835 Lm9977-10483 Lm10949-11664 Lmswitchable
- OpticsDirectGeneral Diffused
- Adjustable
- DimmingDim to 3-10%0-10V
- Controls/NetworkWireless DimmingWaveLinxIntegral Sensor
- Power/VoltageIntegralUNV 120-277V
- Integral EmergencyEM Integral
- Lumen Maintenance160000 h
- CertificatesUL/CULDLC*RoHS
- EnvironmentIP65Vaporproof
- Mounting TypePendantCeiling Surface
- Housing
- Housing Depth
