Neo-Ray (Cooper Lighting Solutions)
S124DR/S124RDR. Define 4 Recessed Direct LED.
Configure
Add to project
RESOURCES
DESCRIPTION
The Define series by Neo-Ray is the ultimate in minimalist simplicity, providing clean, uniform lines of illumination in virtually any architectural environment. Besides delivering outstanding efficacy, it offers unmatched design flexibility with a variety of profile widths and mounting options available.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 3"L: 2 Ft4 Ft8 Ft12 FtRun length (inch)
- Light SourceLED
- CCT/Color2700K3000K3500K4000K5000KTunable White
- CRI80 90
- Watt(Approx)3 W/Ft4.8 W/Ft6.8 W/Ft8.9 W/Ft10.6 W/Ftcustom
- Lumens(Approx)350 Lm/Ft575 Lm/Ft795 Lm/Ft1020 Lm/Ft1195 Lm/Ftcustom
- OpticsDirectGeneral DiffusedAsymmetric/Wash
- Adjustable
- DimmingDim to 3-10%Dim to 1%0-10VDALILutron Hi-lume EcoSystem (LDE1)
- Controls/NetworkEnlightedWaveLinxIntegral Sensor
- Power/VoltageIntegralRemoteUNV 120-277V120V277V347V
- Integral EmergencyEM Integral
- Lumen Maintenance400000 h
- CertificatesUL/CULNYCDLC*T24*RoHSBAA
- EnvironmentDampHealthcare General
- Mounting TypeCeiling RecessedDrywallT-Grid Ceiling
- HousingChicago Plenum
- Housing Depth4.125 ''5.125 ''7.625 ''
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
Lead timeS124DR
Cost
—
CONFIGURATORDESCRIPTIONDIMENSIONSLIGHT SOURCEWATT/LUMENSPOWER/CONTROLSYou reconfigured the product. To remove this message please update you custom description.Marks unavailable product configuration, refer to manufacturer’s documentation for details
BUILD CATALOG NUMBER
