New Star Lighting
DCF. DURACARE FRAME WALL SCONCE SERIES.
Configure
Add to project




RESOURCES
DESCRIPTION
Ligature resistant for Behavioral health applications
Available in nominal 1ft
Field Selectable CCT in 2700K - 5000K
Optional amber (585-600nm) or white night light
Fixture is IP64 rated per IEC60598
Click HERE for the Fall Prevention™ Brochure.
Available in nominal 1ft
Field Selectable CCT in 2700K - 5000K
Optional amber (585-600nm) or white night light
Fixture is IP64 rated per IEC60598
Click HERE for the Fall Prevention™ Brochure.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 1.06"L: 11.89"10.92"13.39"H: 13.86"15.35"
- Light SourceLED
- CCT/Color2700K3000K3500K4000K4500K5000KField Select CCT
- CRI80
- Watt(Approx)11 W
- Lumens(Approx)850 Lm
- OpticsDirectGeneral Diffused
- Adjustable
- DimmingDim to 1%0-10V
- Controls/Network
- Power/VoltageIntegralUNV 120-277V120V277V
- Integral Emergency
- Lumen Maintenance
- CertificatesETL
- EnvironmentHealthcare General
- Mounting TypeWall Surface
- Housing
- Housing Depth
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
