New Star Lighting
DCL. DURACARE LINEAR SERIES.
 Configure
 Add to project
New Star Lighting. DCL. DURACARE LINEAR SERIES.
New Star Lighting. DCL. DURACARE LINEAR SERIES.
RESOURCES
DESCRIPTION
Ligature-resistant for Behavioral Health applications

Available in 2’ - 8’ lengths

Up to 1200 lumens/ft.

One-piece doorframe with continuous lens retention and tamper-resistant fasteners

Certified to UL standards by Intertek Testing Laboratory. IP65 rated per IEC60598. NSF2/Non-Food Zone Listed, IK10 Listed per IEC60068-2-75

This product is Made in America and complies with the Buy American Act requirements
MORE DESCRIPTION
SPECIFICATIONS
  • Dimensions
    W: 4.125"4.945"
    L: 2'3'4'6'8'
  • Light Source
    LED
  • CCT/Color
    3000K3500K4000KTunable White
  • CRI
    80 90
  • Watt(Approx)
    5.26 W/Ft12.43 W/Ft
  • Lumens(Approx)
    500 Lm/Ft1181 Lm/Ft
  • Optics
    DirectGeneral DiffusedAsymmetric/Wash
  • Adjustable
  • Dimming
    Dim to 3-10%Dim to 1%0-10VDALI
  • Controls/Network
  • Power/Voltage
    IntegralUNV 120-277V120V277V347V
  • Integral Emergency
    EM Integral
  • Lumen Maintenance
    50000 h
  • Certificates
    ETLMade in USANSFBAA
  • Environment
    Antimicrobial FinishIP65
  • Mounting Type
    Ceiling RecessedDrywallTrimless DrywallT-Grid CeilingSlot T-Grid CeilingWoodTrimless Wood
  • Housing
    New Construction
  • Housing Depth
 SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
