North Star Lighting
SBX. LED Floodlight.
Configure
Add to project
RESOURCES
DESCRIPTION
Model: SBX LED Floodlight
Lumen Outout: Approximately 70,000 - 100,000 Lumens
Lumens/Watt: 175-250(400W); 140-200(500W); 117-167(600W)
Power: 400W, 500W, 600W
CRI: 70
CCT: 4K (4,000K) 5K (5,000K)
Light Beam Spread (Degrees): 12/17/22/30/45/60
Dimensions (Inches): 16.77(H) x 19.29(W) x 11.46(D)
Lumen Outout: Approximately 70,000 - 100,000 Lumens
Lumens/Watt: 175-250(400W); 140-200(500W); 117-167(600W)
Power: 400W, 500W, 600W
CRI: 70
CCT: 4K (4,000K) 5K (5,000K)
Light Beam Spread (Degrees): 12/17/22/30/45/60
Dimensions (Inches): 16.77(H) x 19.29(W) x 11.46(D)
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 11.5"L: 19.3"H: 16.8"
- Light SourceLED
- CCT/Color4000K5000K
- CRI70
- Watt(Approx)400 W500 W600 W
- Lumens(Approx)72936 Lm88914 Lm103750 Lm
- OpticsDirectNarrowMediumFloodWide Flood
- AdjustableAdjustable
- DimmingDim to 3-10%Non-Dim0-10V
- Controls/Network
- Power/VoltageIntegralUNV 120-277V220-240VUNC 347-480V
- Integral Emergency
- Lumen Maintenance67000 h
- CertificatesCSA
- EnvironmentDampIP66
- Mounting TypeWall SurfaceYokeSlip Fitter
- Housing
- Housing Depth
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
Lead timeSBX
Cost
—
CONFIGURATORDESCRIPTIONDIMENSIONSLIGHT SOURCEWATT/LUMENSPOWER/CONTROLSYou reconfigured the product. To remove this message please update you custom description.Marks unavailable product configuration, refer to manufacturer’s documentation for details
BUILD CATALOG NUMBER
