PureEdge Lighting
LC45. LIGHT CHANNEL 45° DIY SURFACE MOUNT 24VDC, STATIC & TUNABLE WHITE, WARM DIM, RGB, MONOCHROMATIC COLOR & RGBTW.
 Configure
 Add to project
Pure Edge Lighting. LC45. LIGHT CHANNEL 45° DIY SURFACE MOUNT 24VDC LED DO-IT-YOURSELF DYNAMIC WHITE/TUNABLE WHITE, WARM DIM, RGB.
Pure Edge Lighting. LC45. LIGHT CHANNEL 45° DIY SURFACE MOUNT 24VDC LED DO-IT-YOURSELF DYNAMIC WHITE/TUNABLE WHITE, WARM DIM, RGB.
Pure Edge Lighting. LC45. LIGHT CHANNEL 45° DIY SURFACE MOUNT 24VDC LED DO-IT-YOURSELF DYNAMIC WHITE/TUNABLE WHITE, WARM DIM, RGB.
Pure Edge Lighting. LC45. LIGHT CHANNEL 45° DIY SURFACE MOUNT 24VDC LED DO-IT-YOURSELF DYNAMIC WHITE/TUNABLE WHITE, WARM DIM, RGB.
RESOURCES
DESCRIPTION
  • Cut and assemble in field
  • Snap & Light Solderless Connections reduce labor during installation
  • 24VDC LED Soft Strip offers excellent color-rendering inside a slim, paintable aluminum extrusion
  • 5oz of copper provides better heat dissipation, less voltage drop.
  • Surface mount channel is sold in 2', 4', 5', 8' and 10' increments
  • Warm Dim, Dim-To-Warm: (30D) dims from 3000K to 2000K, (27D) dims from 2700K to 2000K. 5 watt only.
  • Tunable White: 2K6K and 27K6 Variable White Tunable Lighting. Human Centric Lighting 5 watt only.
  • Static White Options: Wattage 2.5W | 5W | 7.5W Kelvin Range 2000K-5700K
  • Dynamic Color: RGB 5W only
  • Static Color: Amber (AAA), Green (GGG), Blue (BBB), Red (RRR)
MORE DESCRIPTION
SPECIFICATIONS
  • Dimensions
    W: 0.9"
    L: Run length (Ft)
    H: 0.9"
  • Light Source
    LED
  • CCT/Color
    2400K or less2700K2700K Dim to Warm3000K3000K Dim to Warm3500K4000KTunable WhiteTunable White & ColorsRGBRGBWYellow/AmberRedGreenBlue
  • CRI
    92
  • Watt(Approx)
    2.5 W/Ft2.6 W/Ft4.4 W/Ft4.8 W/Ft5 W/Ft4.6 W/Ft6.3 W/Ft7 W/Ft7.3 W/Ft7.5 W/Ft
  • Lumens(Approx)
    173 Lm/Ft179 Lm/Ft242 Lm/Ft362 Lm/Ft451 Lm/Ft500 Lm/Ft380 Lm/Ft332 Lm/Ft669 Lm/Ft631 Lm/Ft548 Lm/Ft705 Lm/Ft554 Lm/Ft1033 Lm/Ft
  • Optics
    DirectGeneral Diffused
  • Adjustable
  • Dimming
    Dim to 3-10%TRIAC/Forward/LeadingELV/Reverse/Trailing0-10VDALILutron Hi-lume EcoSystem (LDE1)
  • Controls/Network
    Wireless Dimming
  • Power/Voltage
    Remote
  • Integral Emergency
  • Lumen Maintenance
    50000 h
  • Certificates
    ETLMade in USAT24*
  • Environment
    Damp
  • Mounting Type
    Surface
  • Housing
  • Housing Depth
 SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
