LCMG.6. LIGHT CHANNEL 0.6” DIY SURFACE MOUNT MICRO GRAZER 24VDC, DO-IT-YOURSELF IN STATIC & TUNABLE WHITE, WARM DIM, RGB, MONOCH

LCMG6-DIY

Lead time Cost —

SPEC SHEET WHERE TO BUY MANUFACTURER'S PAGE

Pure Edge Lighting

LCMG.6. LIGHT CHANNEL 0.6” DIY SURFACE MOUNT MICRO GRAZER 24VDC, DO-IT-YOURSELF IN STATIC & TUNABLE WHITE, WARM DIM, RGB, MONOCHROMATIC COLOR & RGBTW.
SPECIFICATIONS

CONFIGURATOR

Dimensions
W: 0.7"
L: 2 Ft4 Ft5 Ft8 Ft10 FtRun length (inch)
H: 0.76"
Light Source
LED
CCT/Color
2400K or less2700K2700K Dim to Warm3000K3000K Dim to Warm3500K4000K5700KTunable WhiteRGBYellow/AmberRedGreenBlue
CRI
84 85 80 90 95
Watt^(Approx)
2.3 W/Ft2.5 W/Ft3.5 W/Ft4.4 W/Ft4.8 W/Ft5 W/Ft7.3 W/Ft
Lumens^(Approx)
76.8 Lm/Ft127.8 Lm/Ft293 Lm/Ft402 Lm/Ft738 Lm/Ft1207 Lm/Ft
Optics
DirectGeneral Diffused
Adjustable
Dimming
Dim to 3-10%TRIAC/Forward/LeadingELV/Reverse/Trailing0-10VLutron Hi-Lume 3DLutron Hi-Lume 2-wire (LTEA)DMX
Controls/Network
Wireless Dimming
Power/Voltage
RemoteUNV 120-277V120V
Integral Emergency
Lumen Maintenance
50000 h
Certificates
ETLMade in USAT24*
Environment
Damp
Mounting Type
Surface
Housing
Housing Depth

Description:

DESCRIPTION

DIMENSIONS

LIGHT SOURCE

WATT/LUMENS

POWER/CONTROLS

i You reconfigured the product. To remove this message please update you custom description.

SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.

CONFIGURATOR

Marks unavailable product configuration, refer to manufacturer’s documentation for details

BUILD CATALOG NUMBER

PRODUCT DESCRIPTION
—

Features & Benefits
Cut and assemble in field
Snap & Light Solderless Connections reduce labor during installation
24VDC LED Stomp Strip inside a slim, paintable aluminum extrusion offers excellent color-rendering
5 oz of copper provides better heat dissipation, less voltage drop
Surface mount channel is sold in 2, 4, 5, 8, and 10 foot increments
Static White Options: 2.5W I 5W I 7.5W Options 2000K-5700K options.
Warm Dim, Dim-To-Warm: 30D dims from 3000K to 2000K, 27D dims from 2700K to 2000K. 5 watt only.
Tunable White: 2000K to 4000K Variable White Tunable Lighting. Human Centric Lighting
Dynamic Color: (RGB)
Static Color: Amber (AAA), Green (GGG), Blue (BBB), Red (RRR)
Clear 7° Lens provides maximum light levels and will show LED dots
Linear Frosted Lens projects 20° lines of light, some LED dotting
Low voltage up to 100 watt, Class 2 wiring, no need for conduit pipe
50-watt power supply fits in J Box (PS-60L-ELV-24VDC)
5 year prorated warranty included
