LS. LAZER STRIP COB MONOCHROMATIC COLOR 3W & 5W, 24VDC.
Configure
Add to project
RESOURCES
DESCRIPTION
- 148 LEDs per foot provide uniform light distribution without pixelation
- Offered with Snap & Light, Pin Connectors or, Pre-soldered leads reducing time and labor during installation
- Gold Plated Contacts prevent oxidation to ensure longevity of LED
- 4 oz of copper with 12 mm wide board provides better heat dissipation and less voltage drop
- 24VDC LED Lazer Strip COB (Chip on Board)
- Monochromatic Color Options: Amber, Red, Blue, and Green
- Solid State Power Supply offers 85-90% efficiency compared to magnetic at 80%
- Average life is 50,000 hours
- Includes a 5-year pro-rated warranty
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 0.47"L: Run length (Ft)
- Light SourceLED
- CCT/ColorYellow/AmberRedGreenBlue
- CRI
- Watt(Approx)3.3 W/Ft4.4 W/Ft
- Lumens(Approx)
- OpticsDirectGeneral Diffused
- Adjustable
- DimmingDim to 3-10%TRIAC/Forward/LeadingELV/Reverse/Trailing0-10V
- Controls/Network
- Power/VoltageRemote
- Integral Emergency
- Lumen Maintenance50000 h
- CertificatesETLRoHS
- EnvironmentDamp
- Mounting TypeSurface
- Housing
- Housing Depth
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
