PureEdge Lighting
MSLO-24V. MINI STAR LINEAR LED OUTDOOR 24VDC 6 OR 9 WATTS DYNAMIC COLOR CHANGING RGB/RGBW.
Configure
Add to project



RESOURCES
DESCRIPTION
Clean lines and a minimal profile combine to create the Mini Star Outdoor Linear LED fixture. The Mini Star is a simple yet technically advanced compact design which is aesthetic while able to deal with internal heat. Its special thermal convection design inside enables heat to be transferred rapidly and allows the fixture to be more compact than traditional light sources. This in combination with High Powered LEDs, make the Mini Star a premium light source. Can be Ceiling, floor, or wall mounted to provide a flood of light, and has wall washing functionality with its selection of lens: RGB has a 12°X53° Oval Beam Spread, and the RGB+W has 22° Round Beam or 24°X45° Oval Beam Spread options. The Mini Star Linear is manufactured with adjustable mounting clips that allow the fixture to be mounted in various outdoor applications. Link multiple fixtures to sync color effects. Single zone control not DMX addressable. Power and Control the Mini Star IP66 Rated fixture combines with a full touch controller and Universal (UNI) power supply (Sold Separately, See Pages 4 & 5). Controller is NOT outdoor rated, and shall be located at a remote indoor location. Multiple Mini Star RGB or RGB+W fixtures can be ganged together up to 100 watts before re-feeding.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 1.7"L: 24"48"H: 2"
- Light SourceLED
- CCT/ColorRGBRGBW
- CRI
- Watt(Approx)12 W18 W24 W36 W
- Lumens(Approx)652 Lm1303 Lm
- OpticsDirectGrazingMedium
- AdjustableAdjustable
- DimmingDim to 3-10%TRIAC/Forward/LeadingELV/Reverse/Trailing0-10V
- Controls/Network
- Power/VoltageRemoteUNV 120-277V
- Integral Emergency
- Lumen Maintenance50000 h
- CertificatesETLRoHS
- EnvironmentIP66
- Mounting TypeSurfaceBrackets
- Housing
- Housing Depth
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
MSLO-24V-RGBW
—
CONFIGURATORDESCRIPTIONDIMENSIONSLIGHT SOURCEWATT/LUMENSPOWER/CONTROLSYou reconfigured the product. To remove this message please update you custom description.Marks unavailable product configuration, refer to manufacturer’s documentation for detailsBUILD CATALOG NUMBER
