VGCE. VERGE CEILING/DOOR DO-IT-YOURSELF 24VDC PLASTER-IN LED SYSTEM.
Configure
Add to project



RESOURCES
DESCRIPTION
Verge Ceiling/Door DIY (Do-It-Yourself) is another innovative design addition to the family of 5/8" Drywall Plaster-in systems pioneered by PureEdge. The 24VDC system contains a slim plaster-in aluminum extrusion and a 4" paintable aluminum backer plate that mounts directly to studs or ceiling joists without any modification and recesses within 5/8" or thicker drywall. Continuing to redefine the relationship between lighting and interior design, the Verge Ceiling/Door elegantly highlights ceiling perimeters while emitting smooth and continuous illumination. Field-cuttable lengths, using our designer-grade High CRI Color Rendering LEDs which are available in many color temperatures: Static White 2200K-5700K, Warm Dim (27D or 30D) and, Tunable White (2K6K and 27K6) as well as three wattage options of 2WDC, 5WDC and 7WDC. Verge brings a modern appearance to residential and commercial environments, offering unlimited creativity, and empowering you to design one-of-a-kind, personalized spaces every time. Remote Power supplies are required and sold separately. Coordinate installation with electrical and drywall contractors. Includes a 5-year prorated warranty. For custom quotes and layout assistance, send drawings to design@PureEdgeLighting.com. Designed by Gregory Kay.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 4.13"L: 4 Ft5 Ft8 Ft10 FtRun length (Ft)
- Light SourceLED
- CCT/Color2400K or less2700K2700K Dim to Warm3000K3000K Dim to Warm3500K4000KTunable WhiteTunable White & ColorsRGBRGBWYellow/AmberRedGreenBlue
- CRI92 94 90
- Watt(Approx)2.5 W/Ft2.6 W/Ft4.4 W/Ft4.8 W/Ft5 W/Ft4.6 W/Ft6.3 W/Ft7.3 W/Ft7.5 W/Ft10 W/Ft12 W/Ft
- Lumens(Approx)173 Lm/Ft208 Lm/Ft362 Lm/Ft451 Lm/Ft500 Lm/Ft669 Lm/Ft631 Lm/Ft548 Lm/Ft705 Lm/Ft1033 Lm/Ft
- OpticsDirectGeneral Diffused
- Adjustable
- DimmingDim to 3-10%Dim to 1%TRIAC/Forward/LeadingELV/Reverse/Trailing0-10VLutron Hi-lume EcoSystem (LDE1)DMX
- Controls/Network
- Power/VoltageRemote
- Integral Emergency
- Lumen Maintenance50000 h
- CertificatesETLMade in USARoHS
- EnvironmentDamp
- Mounting TypeCeiling RecessedDrywall
- HousingFixture
- Housing Depth0.75 ''
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
