PureEdge Lighting
VGCO. VERGE CORNER TUNABLE WHITE 24VDC, 5/8" DRYWALL PLASTER-IN LED SYSTEM.
Configure
Add to project




RESOURCES
DESCRIPTION
Verge Corner Tunable White is another innovative design from PureEdge's family of 24VDC plaster-in systems, continuing to redefine the relationship between lighting and architecture. Verge Corner mounts directly to studs and joists without modification because it recesses within 5/8" or thicker drywall. The slim plaster-in aluminum channel has a 4" paintable backer plate creating visually interesting and dramatic illumination by highlighting the inside Corners of two drywall surfaces such as ceiling, coves, and skylights. Field-cuttable, Verge Corner is ordered in 1' increments up to 40'. Our Designer-grade High CRI Tunable White technology in 2000K-6500K (2K6K) or 2700K-6500K (27K6) grants independent control and adjustment of color temperature and intensity from 2000K (Sunset) through 6500K (Day Light White). Tunable white lighting visually, biologically and emotionally contributes to human interaction with the physical world. Human centric lighting (HCL) builds on this technology bringing the dynamics of natural daylight indoors, and delivering a positive effect on human health, wellbeing and performance. Click here for all Other Color Temperatures. Verge brings together a Modern and Dynamic appearance to Residential and Commercial environments, offering unlimited creativity and empowering you to design One-of-a-kind spaces every time. Remote Power supplies are required and sold separately. Coordinate installation with electrical and drywall contractors. Includes a 5-year pro-rated warranty.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 4"L: Run length (Ft)
- Light SourceLED
- CCT/ColorTunable White
- CRI90
- Watt(Approx)5 W/Ft10 W/Ft15 W/Ft
- Lumens(Approx)174 Lm/Ft340 Lm/Ft479 Lm/Ft
- OpticsDirectGeneral Diffused
- Adjustable
- Dimming
- Controls/Network
- Power/Voltage
- Integral Emergency
- Lumen Maintenance50000 h
- CertificatesETLRoHS
- EnvironmentDamp
- Mounting TypeCeiling RecessedWall RecessedDrywall
- HousingFixture
- Housing Depth0.75 ''
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
VGCO-TW
—
CONFIGURATORDESCRIPTIONDIMENSIONSLIGHT SOURCEWATT/LUMENSPOWER/CONTROLSYou reconfigured the product. To remove this message please update you custom description.Marks unavailable product configuration, refer to manufacturer’s documentation for detailsBUILD CATALOG NUMBER
