VGW. VERGE WALL DO-IT-YOURSELF 24VDC PLASTER-IN LED SYSTEM.
Configure
Add to project



RESOURCES
DESCRIPTION
Verge Wall BIY (Build-It-Yourself) is a 24VDC linear system, with a slim plaster-in aluminum extrusion, and a 4" paintable aluminum backer plate. It mounts directly to studs without joist modification and plasters into 5/8" or thicker drywall. Fixture emits ambient light for dramatic illumination at the ceiling, floor or at the side of the wall. Offered in a spectrum of color temperatures: 2000K-5700K, Static White, Warm Dim (27D or 30D) and, Tunable White (2K4K or 27K6). Coordinate installation with electrical and drywall contractors. Includes a 5-year pro-rated warranty.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsL: 4 Ft5 Ft8 Ft10 FtRun length (Ft)H: 4"
- Light SourceLED
- CCT/Color2400K or less2700K2700K Dim to Warm3000K3000K Dim to Warm3500K4000KTunable WhiteTunable White & ColorsRGBRGBWYellow/AmberRedGreenBlue
- CRI92 94
- Watt(Approx)2.5 W/Ft2.6 W/Ft4.4 W/Ft5 W/Ft6.3 W/Ft7 W/Ft7.3 W/Ft
- Lumens(Approx)362 Lm/Ft410 Lm/Ft669 Lm/Ft543 Lm/Ft1033 Lm/Ft
- OpticsDirectGeneral Diffused
- Adjustable
- DimmingDim to 3-10%Dim to 1%TRIAC/Forward/LeadingELV/Reverse/Trailing0-10VDALILutron Hi-lume EcoSystem (LDE1)DMX
- Controls/Network
- Power/VoltageRemote120V
- Integral Emergency
- Lumen Maintenance50000 h
- CertificatesETLMade in USARoHS
- EnvironmentDamp
- Mounting TypeCeiling RecessedWall RecessedDrywall
- HousingFixture
- Housing Depth0.75 ''
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
VGW-DIY
—
CONFIGURATORDESCRIPTIONDIMENSIONSLIGHT SOURCEWATT/LUMENSPOWER/CONTROLSYou reconfigured the product. To remove this message please update you custom description.Marks unavailable product configuration, refer to manufacturer’s documentation for detailsBUILD CATALOG NUMBER
