Picasso Lighting
PMX 4-RF. P-Max 4 Flush Lens PERIMETER WALL WASH.
Configure
Add to project
RESOURCES
DESCRIPTION
- Perimeter wall application
- Flush with ceiling or 1-3" regressed 4 inch LED linear snap-in lens
- Sleek, slender contemporary design
- Easy to install and service
- T-Grid, S-Slot Grid, Sheetrock
- Special - no light leak ends feature
- Telescoping End- Specify length and we will set it to + or - 3" on end.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 4 1/8"4 7/8"4 1/2"L: 2'3'4'5'6'7'8'Run length (Ft)
- Light SourceLED
- CCT/Color2700K3000K3500K4000KTunable White
- CRI80 90
- Watt(Approx)3.8 W/Ft5.4 W/Ft8 W/Ft10.7 W/Ft
- Lumens(Approx)350 Lm/Ft500 Lm/Ft750 Lm/Ft1000 Lm/Ft
- OpticsDirectGeneral Diffused
- Adjustable
- DimmingDim to 3-10%Dim to 1%Non-Dim0-10VDALILutron EcoSystem 5 (LDE5)Lutron EcoSystemDMX
- Controls/NetworkEthernetIntegral Sensor
- Power/VoltageIntegralPoE120V277V
- Integral EmergencyEM Integral
- Lumen Maintenance50000 h
- CertificatesUL/CULMade in USAIBEW
- EnvironmentDamp
- Mounting TypeCeiling RecessedDrywallTrimless DrywallT-Grid CeilingSlot T-Grid Ceiling
- HousingNew ConstructionICChicago Plenum
- Housing Depth3 3/8 ''4 3/8 ''5 3/8 ''6 3/8 ''
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
Lead timePMX4-RF
Cost
—
CONFIGURATORDESCRIPTIONDIMENSIONSLIGHT SOURCEWATT/LUMENSPOWER/CONTROLSYou reconfigured the product. To remove this message please update you custom description.Marks unavailable product configuration, refer to manufacturer’s documentation for details
BUILD CATALOG NUMBER
