MIR. MicroCovePro COVE & PERIMETER Remote Driver.
Configure
Add to project
RESOURCES
DESCRIPTION
Diminutive in scale, huge in performance, MicroCove is a concealed cove luminaire designed to optimize all the benefits of the LED source.
- Our proprietary PruOptics creates even distribution while maintaining extraordinarily high efficiences (up to 107 lm/w)
- Up to 30 degrees of tilt for vaulted ceilings
- Remote driver option for tiny coves
- Stack mount option for narrow coves
- Vertically mount in a Slot for wall wash effect
- 2014 IES Progress Report award winner
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 2 7/8"L: 1 Ft2 Ft3 Ft4 Ft6 Ft8 FtRun length (Ft)H: 2 1/2"
- Light SourceLED
- CCT/Color2700K2700K Dim to Warm3000K3000K Dim to Warm3500K3500K Dim to Warm4000K5000KTunable WhiteRGBW
- CRI90 80
- Watt(Approx)4.6 W/Ft6.5 W/Ft9.5 W/Ft11 W/Ftcustom
- Lumens(Approx)510 Lm/Ft725 Lm/Ft1010 Lm/Ft1170 Lm/Ftcustom
- OpticsDirectAsymmetric/Wash
- AdjustableAdjustable
- DimmingDim to 3-10%Dim to 1%Dim to <1%Non-Dim0-10VLutron Hi-lume EcoSystem (LDE1)eldoLED DUAL DALIeldoLED POWER DMX/RDMeldoLED ECO DALIeldoLED ECO 0-10VeldoLED SOLO DALIeldoLED SOLO 0-10VEldoLED DUAL 0-10V
- Controls/Network
- Power/VoltageIntegralUNV 120-277V347V
- Integral Emergency
- Lumen Maintenance150000 h
- CertificatesETLMade in USAIBEWDeclare
- EnvironmentDamp
- Mounting TypeSurface
- Housing
- Housing Depth
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
