Prudential Lighting
PRU1. Pru1 Linear.
 Configure
 Add to project
DESCRIPTION
“I want to see light, not light fixtures.”

In the spirit of “less is more,” we’ve designed Pru1 with minimal form linear D/I illumination, nearly invisible hanging hardware options, and a Ceiling Wash that limits the intensity directly above the fixture, creating a more evenly lit ceiling. See our Pru1 Wall Wash spec sheet to achieve a fully cohesive look with sleek, subtle illumination throughout the entire space.

  • 1.5˝ diameter Direct/Indirect, Direct, Indirect, Asymmetric
  • 1.75˝ with Louver
  • Ceiling Wash for even ceiling illumination
  • Flat + Focal Glow Wall Washes
  • Power Over Aircraft cable, no power cord option
  • Nearly invisible .5˝ hanging hardware (T-bar)
MORE DESCRIPTION
SPECIFICATIONS
  • Dimensions
    W: 1 11/16"1 1/2"
    L: 2'3'4'5'6'7'8'Run length (Ft)
    H: 1 11/16"1 1/2"
  • Light Source
    LED
  • CCT/Color
    2700K3000K3500K4000K5000K
  • CRI
    90 80
  • Watt(Approx)
    3 W/Ft4.75 W/Ft7 W/Ft9.25 W/Ftcustom
  • Lumens(Approx)
    250 Lm/Ft270 Lm/Ft425 Lm/Ft450 Lm/Ft600 Lm/Ft625 Lm/Ft825 Lm/Ft850 Lm/Ftcustom
  • Optics
    DirectIndirectDirect/IndirectGeneral Diffused
  • Adjustable
  • Dimming
    Dim to 1%Dim to <1%Step DimNon-Dim0-10VLutron Hi-lume EcoSystem (LDE1)eldoLED ECO DALIeldoLED ECO 0-10VeldoLED SOLO DALIeldoLED SOLO 0-10V
  • Controls/Network
  • Power/Voltage
    IntegralUNV 120-277V347V
  • Integral Emergency
    EM Integral
  • Lumen Maintenance
    150000 h
  • Certificates
    CSAMade in USAIBEWDeclareBAA
  • Environment
    Damp
  • Mounting Type
    PendantWall Arm/Cantilever
  • Housing
  • Housing Depth
 SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
