Sternberg Lighting
9403LED. STATE LED SERIES.
Configure
Add to project
RESOURCES
DESCRIPTION
The 9403 fixture is made of heavy wall cast aluminum, 356 alloy, and acrylic lenses. The fixture cage is a one piece cast aluminum. The fixture is appointed with a cast square cupola house or a 6” tall roof finial. The Luminaire shall be UL listed in US and Canada.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 15 1/2"L: 15 1/2"H: 26 3/8"30 1/2"36 1/8"
- Light SourceLED
- CCT/Color2700K3000K3500K4000K5000K
- CRI70
- Watt(Approx)19 W29 W40 W62 W
- Lumens(Approx)2100 Lm3450 Lm4715 Lm7115 Lm
- OpticsDirectType IIType IIIType IVType V
- Adjustable
- DimmingDim to 3-10%0-10V
- Controls/NetworkIntegral Sensor
- Power/VoltageIntegralUNV 120-277VUNC 347-480V
- Integral Emergency
- Lumen Maintenance50000 h
- CertificatesUL/CUL
- Environment
- Mounting TypePole/Mast ArmPole/Post TopPendantWall Arm/CantileverCatenaryBase
- Housing
- Housing Depth
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
Lead time9403LED
Cost
—
CONFIGURATORDESCRIPTIONDIMENSIONSLIGHT SOURCEWATT/LUMENSPOWER/CONTROLSYou reconfigured the product. To remove this message please update you custom description.Marks unavailable product configuration, refer to manufacturer’s documentation for details
BUILD CATALOG NUMBER
