STR2. 2'' Track Luminaire.
Configure
Add to project




RESOURCES
DESCRIPTION
Spectrum’s 2" track series features machined aluminum body, integral driver, TIR (Total Internal Reflection) optics, variety of bezels, and anodized or textured powder coat color choices. The STR2 has a clean profile, just like our CR2 pendant. STR2 can be used on five different tracks (120v or 277v) and is available with six different bezels, four architectural finishes for body and eight for the bezel, for a mix or match customized look. All bezels, except acrylics, feature anti-glare matte black finish and can accept up to 2 accessories, while wall wash has an anti-glare finish but cannot accept accessories. Bias and Wall Wash bezels rotate 360 degrees. TIR optics are field changeable and available in beam distributions from 12° to 60°. TIR optics can be paired with various accessories including hex cell, linear spread and diffusing or clear lenses.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 2 1/2"L: 2 1/2"H: 10 9/16"
- Light SourceLED
- CCT/Color2400K or less2700K3000K3000K Dim to Warm3500K4000K
- CRI80 90
- Watt(Approx)6.9 W11.8 W14.4 W
- Lumens(Approx)779 Lm1062 Lm1416 Lm
- OpticsDirectNarrowMediumFloodWide FloodAsymmetric/Wash
- AdjustableLock Aiming
- DimmingDim to 1%Non-DimTRIAC/Forward/LeadingELV/Reverse/Trailing0-10V
- Controls/Network
- Power/VoltageRemote120V277V
- Integral Emergency
- Lumen Maintenance67000 h
- CertificatesETLMade in USA
- EnvironmentDamp
- Mounting TypeTrack/Busway
- Housing
- Housing Depth
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
Lead timeSTR2
—
