The new VSX-II Array LED Series offers clean, functional styling that is defined by its sleek low profile design and rugged construction. It combines the latest LED Array technology, advanced LED thermal management and provides outdoor lighting that is both energy efficient and aesthetically pleasing.
The LED’s performance and the driver’s life are maximized by enclosing them in two separate die cast aluminum housings.
The VSX-II Array LED fixture is offered with lumen packages ranging from 5,000 – 25,000. Ten optical distribution patterns are available. Choose between 3000, 4000 or 5000 Kelvin temperature of the LEDs.
A durable polyester powder coat finish is guaranteed for five years; and is available in standard or custom colors.
The VSX-II Array LED series is an exceptional choice for commercial parking lots, office complexes, architectural projects, and other general lighting projects.
The LED’s performance and the driver’s life are maximized by enclosing them in two separate die cast aluminum housings.
The VSX-II Array LED fixture is offered with lumen packages ranging from 5,000 – 25,000. Ten optical distribution patterns are available. Choose between 3000, 4000 or 5000 Kelvin temperature of the LEDs.
A durable polyester powder coat finish is guaranteed for five years; and is available in standard or custom colors.
The VSX-II Array LED series is an exceptional choice for commercial parking lots, office complexes, architectural projects, and other general lighting projects.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 10.69"L: 23.16"23.22"23.08"23.09"22.99"23"24.31"H: 4"
- Light SourceLED
- CCT/Color3000K4000K5000K
- CRI70
- Watt(Approx)34 W70 W102 W134 W167 W
- Lumens(Approx)5111 Lm9838 Lm15441 Lm19899 Lm24601 Lm
- OpticsDirectType IType IIType IIIType IVType V
- AdjustableAdjustable
- DimmingDim to 3-10%0-10V
- Controls/NetworkWireless DimmingIntegral Sensor
- Power/VoltageIntegralUNV 120-277V347V480V
- Integral Emergency
- Lumen Maintenance100000 h
- CertificatesUL/CULDark SkyDLC*
- EnvironmentIP65
- Mounting TypePole/Mast ArmWall SurfaceWall Arm/CantileverKnuckleTenon Adapter
- Housing
- Housing Depth
